ETHERNET
8 x Ethernet ports, 10/100/1000 Mbps, supports auto MDI/MDIX crossover
2 x SFP ports
IEEE 802.3 series standards : 802.3i, 802.3u, 802.3ab, 802.3x, 802.3az
PoE ports 1 - 8
PoE standards: 802.3af and 802.3at Alternative B
PoE Max Power per Port (at PSE): 30 W
Total PoE Power Budget (at PSE): 240 W
PERFORMANCE SPECIFICATIONS
Bandwidth (Non-blocking): 20 Gbps
Packer buffer: 128 KB
MAC address table size: 2K entries
Jumbo frame support: 9216 bytes
POWER Connector: 2-pin industrial DC power socket + 1 x Grounding screw
Input voltage range: 7 – 57 VDC
PoE-out input voltage range: 44 – 57 VDC
Power consumption: Idle: 1.81 W / Max: 5.5 W / PoE Max: 245.5 W
PHYSICAL SPECIFICATION
Casing material: Full aluminum housing
Dimensions (W x H x D): 132 x 44.2 x 95.1 mm
Weight: 517 g
OPERATING ENVIRONMENT
Operating temperature: -40 °C to 75 °C
Operating humidity: 10% to 90% non-condensing
Ingress Protection Rating: IP30
REGULATORY & TYPE APPROVALS
Regulatory: CE, UKCA, CITC, ANRT, FCC, IC, CB
